Sea Water Filtration Polyester Screen Mesh 20, 40, 80, 100, 120, 150, 180, 400, 500, 700, 1000, 1500 Microns

Product Description



SHARE polyester filter screen mesh are frequently used on sea water, aquaculture farms, hatcheries and in research laboratory settings. They are used for filtration or size sorting where precise hole size is critical. Polyester is one of the strongest fibers and remains resistant even if it gets wet and exposed to friction. Its low moisture absorbency prevents it from expanding, contracting, becoming wrinkled, and it also features resistance to chemicals, as well as being less likely to be damaged by insects and molds.

Polyester is better than nylon in situations where screens need regular cleaning, face UV rays, or stay underwater for a long time.





Heat Resistance	Softening point : 238-240ºC Melting point : 255-260ºC
Specific Gravity	1.38
Chemical Resistance	Highly resistant and shows little to no change after exposure to concentrated hydrochloric acid, 75% sulfuric acid, concentrated filtered nitric acid, 10% caustic soda solution, and 28% ammonia solution
Weather Resistance	Highly resistant and shows little to no change
Insect and Mold Resistance	Completely resistant





The polyester filter meshes we recommend for sea water filtration are:

SHARE polyester mesh 20, 40, 80, 100, 120, 150, 180, 400, 500, 700, 1000, 1500 µm microns mesh opening







Specifications



Product name	20, 40, 80, 100, 120, 150, 180, 400, 500, 700, 1000, 1500 Microns Sea Water Filtration Polyester Screen Mesh
Manufacturer	Taizhou Share Filters Co. Ltd.
Brand	SHARE FILTERS
Material	100% polyester monofilament mesh
Color	White, yellow, black or other colors
Weave type	Plain woven, twill woven, dutch woven
Common width	50cm, 100cm, 127cm, 150cm, 160cm, 175cm, 183cm, 220cm, 260cm, 310cm, 330cm, 365cm or customized
Roll length	30-100 meters or customized
Mesh count/cm	DPP8T-DPP200T
Mesh count/inch	20 mesh/inch-508 mesh/inch
Thread diameter	27um to 600um
Micron rating	20, 40, 80, 100, 120, 150, 180, 400, 500, 700, 1000, 1500 microns
Thickness	41um to 1170um
Certificate	ISO19001 SGS ROHS REACH
Samples availability	1 meter free
Size	1. Cut the support screen mesh to the width required by the customer, roll it for delivery, and let customers cut it to their desired length for their use. 2 Cut the filter screen mesh into individual mesh pieces so that customers can use them directly.
Package	1. 30-70m/roll in PVC bag 2. 2-8 rolls per carton 3. Waterproof bags outside 4. Package belt strengthen
Features	1. Great dimensional stability, accurate and even mesh opening, smooth surface, excellent tear resistance, high tensile strength, good air permeability, high chemical resistance, good acid and solvent resistance, temperature resistance, low moisture absorbency 2. Available in various shapes: disc, ribbon, belt, tube, bag, and special shapes 3. Compliance with food grade standards 4. RoHS and REACH certified
Quality control	Visual inspection, optical or pressure sensitive equipment and automated 3D image-inspection equipment
Application	Solvents filtration, liquid filtration, dust collection or separation, dry and wet filter bags, sifting, milling, automotive, medical, food, pharmaceutical, white goods, injection molding, filter belts, loudspeaker and microphone front, waterproofing acoustic appliances, interior design, clothing, refining, decoration





Technical Datasheet



SHARE Precision Polyester Filter Mesh Technical Data Sheet
Fabric number	Mesh count		Thread diameter	Mesh opening	Open area	Fabric thickness	Weight
NO.	mesh/cm	mesh/inch	micron	micron	%	micron	g/m2
PES 4400/77.5	2T	5	600	4400	77.5	1170	156
PES 2750/67.2	3T	8	600	2750	67.2	1160	234
PES 2000/64	4T	10	500	2000	64	950	217
PES 1550/60	5T	13	450	1550	60	850	259
PES 1270/58	6T	15	400	1270	58	760	246
PES 1080/57	7T	18	350	1080	57	660	220
PES 900/52	8T	20	350	900	52	660	251
PES 760/47	9T	23	350	760	47	670	282
PES 800/64	10S	25	200	800	64	360	87
PES 750/56	10	25	250	750	56	450	160
PES 700/49	10T	25	300	700	49	570	231
PES 720/74	12S	30	120	720	74	215	44
PES 680/67	12	30	150	680	67	260	69
PES 580/48	12	30	250	580	48	460	192
PES 530/40	12T	30	300	530	40	580	277
PES 515/52	14S	36	200	515	52	360	143
PES 470/50	15S	38	200	470	50	380	154
PES 420/40	15T	38	250	420	40	470	240
PES 525/92	16S	41	100	525	92	180	36
PES 425/46	16T	41	200	425	46	380	164
PES 405/53	18S	46	150	405	53	260	104
PES 375/46	18T	46	180	375	46	330	150
PES 375/51	19T	48	150	375	51	260	110
PES 420/71	20S	50	80	420	71	140	33
PES 400/64	20S	50	110	400	64	180	51
PES 350/49	20T	50	150	350	49	260	115
PES 325/47	21T	53	150	325	47	270	121
PES 340/67	24S	61	120	340	67	220	88
PES 270/42	24T	61	150	270	42	280	138
PES 250/46	27T	68	120	250	46	230	100
PES 280/62	28S	71	80	280	62	150	46
PES 240/45	28T	71	120	240	45	230	103
PES 225/43	29T	74	120	225	43	230	107
PES 215/42	30T	76	120	215	42	230	111
PES 230/54	32S	80	80	230	54	150	52
PES 210/45	32T	80	100	210	45	180	82
PES 215/53	34S	86	80	215	53	150	56
PES 195/44	34T	86	100	195	44	180	87
PES 180/42	36T	91	100	180	42	180	92
PES 200/61	39S	99	55	200	61	95	30
PES 190/55	39T	99	64	190	55	115	40
PES 150/36	40T	102	100	150	36	190	103
PES 150/42	43T	110	80	150	42	155	71
PES 160/57	47S	120	55	160	57	96	36
PES 150/50	47T	120	64	150	50	120	48
PES 140/43	47HD	120	71	140	43	130	59
PES 140/47	49S	125	64	140	47	120	50
PES 135/44	49T	125	71	135	44	130	62
PES 144/55	53S	135	45	144	55	76	27
PES 135/51	53S	135	55	135	51	97	40
PES 125/44	53T	135	64	125	44	122	54
PES 117/39	53T	135	71	117	39	132	67
PES 115/46	59S	150	55	115	46	99	45
PES 105/38	59T	150	64	105	38	123	61
PES 100/41	64S	160	55	100	41	100	48
PES 90/33	64T	160	64	90	33	125	66
PES 95/47	72S	180	45	95	47	78	37
PES 85/38	72T	180	55	85	38	102	55
PES 75/33	77T	195	55	75	33	105	58
PES 80/41	80S	200	45	80	41	80	41
PES 85/44	80T	200	48	85	44	86	44
PES 70/40	90M	230	39	70	40	68	34
PES 68/34	90T	230	45	68	34	80	46
PES 65/33	90T	230	48	65	33	82	49
PES 60/36	100T	250	39	60	36	69	38
PES 56/38	110T	280	34	56	38	62	34
PES 52/33	110HD	280	39	52	33	70	42
PES 52/40	120S	300	31	52	40	48	32
PES 48/33	120T	300	34	48	33	63	37
PES 44/28	120HD	300	39	44	28	72	46
PES 47/37	130S	330	31	47	37	50	35
PES 42/30	130T	330	34	42	30	58	40
PES 43/34	140S	350	31	43	34	50	37
PES 36/25	140T	355	34	36	25	62	43
PES 37/30	150S	380	31	37	30	50	40
PES 32/24	150	381	34	32	24	56	43
PES 33/31	165S	420	27	33	31	40	26
PES 32/23	165T	420	31	32	23	50	36
PES 25/16	165	419	34	25	16	66	49
PES 24/18	180	457	27	24	18	43	33
PES 23/17	180	457	31	23	17	56	40
PES 18/18	235x245	597x622	24	18	18	44	32
PES 18/13	200	508	31	18	13	60	48
PES 23/25	200T	500	27	23	25	45	32
PES 15/10	200x215	508x546	31	15	10	59	50



Mesh Count: Number of openings per inch or centimeter
Weave Type: Plain Weave (PW) or Twill Weave (TW)
Thread Diameter: The diameter of each thread before weaving
Mesh Thickness: The average thickness of the woven mesh
Mesh Opening: The distance between adjacent threads
Open Area: The ratio (%) of the open area to the thread area within a woven mesh



The data are compiled to the best of our knowledge.
Subject to change without notice.
Complete product range is available on request.



What is Plain Weave(PW) and Twill Weave(TW) for Filter Mesh?























Plain weave is made by crossing the warp and weft yarns with each other, which is the simplest weave among textile structures. Well-regulated and highly durable textile fabrics can be created as there are many points where the threads cross each other (structure points). It is also resistant to friction.
Since the warp and weft yarns appear on the front and rear surfaces of the textile uniformly, it is sometimes difficult to make a distinction between the front side and the rear side compared to other structures.



































Twill weave is a structure created by intersecting warp and weft yarns. Each yarn is woven by at least skipping two or more of the opposing yarn either over or under. Slanting ribs like "/" can be seen as a diagonal pattern on the fabric surface. This slanting line is called the "twill line."
Twill weave yard has a slightly lower durability, but is more flexible and has a glossy texture compared to plain weave as the warp of a twill weave yarn will cover a larger surface area. (warp yarns are floated in a wider area).
As there are fewer interlacing threads, high-density textile fabrics with fewer spaces can be created.
A weave in which the weft yarns are crossed by two upper and two lower warp yarns is called "2/2 twill weave", and weaves in which weft yarns are crossed by two upper and one lower and three upper and one lower warp yarns are called "2/1 twill weave" and "3/1 twill weave," respectively. A wide variety of structures that cannot be realized with a plain weave can be created.










Gallery



By cold, heat, ultrasonic, laser, injection mold and many more technologies, SHARE can process filter mesh into various specific solutions including colored, coated, thermal treated, sectioned, shaped, pleated, sewed or molded products based on customers' requirements. Contact us now for more information about our filter mesh.



1. Rolled on the paper core, 30-70m/roll, packed into PE bags, the product label is attached on the edge of each roll
2. 2-8 rolls per standard export carton
3. Put into PP woven bag to prevent damage during transportation
4. Package belt strengthen

For fabricated & molded filters:

1. Packed into sealed PE bags, 10m2 to 500m2/bag according to the actual size, double bagged and the product label is attached in the inner bag
2. Put into bigger PE bag and then standard export carton
3. Wrapped the outer carton with PE stretch film to prevent damage during transportation
4. Package belt strengthen if pallets are available

The label contains the following standard information:
item name, manufacturer, material, dimensions, manufacturing date, order number, batch number etc.
