Plain Woven Monofilament Polyester Screen Fabric For Sieving Particles in Liquid Filtration
Contact Person : Eric Xiang
Phone Number : +86-18658318635
WhatsApp : +8613968584834
Minimum Order Quantity : | 100meters | Price : | USD0.2-USD3.5/m |
---|---|---|---|
Packaging Details : | Carton | Delivery Time : | 3-30days |
Payment Terms : | L/C, T/T, Western Union, MoneyGram | Supply Ability : | 1000meters/day |
Place of Origin: | CHINA | Brand Name: | SHARE |
---|---|---|---|
Certification: | SGS | Model Number: | JPP10T-JPP200T |
Detail Information |
|||
Material: | 100% Monofilament Polyester Yarn | Name: | Polyester Filter Mesh |
---|---|---|---|
Thread Diameter: | 27um-550um | Micron Rating: | 5um-1500um |
Width: | 110cm-190cm | Color: | Natural White |
Characteristics: | High Tension, Low-Elongation, High Tenacity | Application: | Liquid Filtration, Oil/fuel Filtration |
Highlight: | monofilament polyester mesh,polyester mesh filter |
Product Description
Blood Filtration Mesh made of PA6.6 Monofilament Polyamide Yarn
Monofilament Polyamide Filter Mesh
Mesh Count: JPP5T-JPP200T
Thread Diameter: 27um-550um
Micron Rating: 5um-1500um
Width: 110cm-190cm
Introduction:
Selecting quality monofilament Polyamide Yarn with abrasion-resistance, good chemical stability, SHARE carefully weaves polyamide filter mesh with Sulzer P7100 looms; More than 30 years of production experience enables us to weave Polyamide filter mesh with precise mesh holes and thanks to the after-production treatment of heat-setting, polyamide filter mesh has stable yarn conection without yarn migration during use, precision mesh holes, good dimensional stability.
Advantages of Polyester Filter Mesh
High Tenacity, High Tension, Low-elongation, Anti-wrinkling, anti-mildew, good chemical characteristics
Application:
Liquid Filtration, Oil Filtration, Water Filtration, Petroleum Filtration
Datasheet:
Fabric Number | Mesh count | Thread Diameter | Mesh Opening | Open Area | Fabric Thickness | Weight | |
No. | cm mesh/inch | micron | micron | % | micron | g/m2 | |
JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 | 271 |
JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 | 208 |
JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 | 186 |
JPP8 | 8 | 20 | 350 | 900 | 52 | 685 | 212 |
JPP9 | 9 | 24 | 250 | 860 | 60 | 455 | 145 |
JPP10 | 10 | 25 | 300 | 700 | 49 | 576 | 195 |
JPP12 | 12 | 30 | 250 | 583 | 49 | 470 | 162 |
JPP12 | 12 | 35 | 300 | 533 | 41 | 585 | 234 |
JPP14 | 14 | 40 | 300 | 414 | 34 | 595 | 273 |
JPP16 | 16 | 40 | 200 | 425 | 46 | 370 | 139 |
JPP16 | 16 | 50 | 250 | 375 | 36 | 485 | 217 |
JPP20 | 20 | 50 | 150 | 350 | 49 | 375 | 98 |
JPP20 | 20 | 50 | 200 | 300 | 36 | 385 | 173 |
JPP24 | 24 | 60 | 150 | 267 | 41 | 285 | 117 |
JPP28 | 28 | 70 | 120 | 237 | 44 | 215 | 87 |
JPP30 | 30 | 76 | 120 | 213 | 41 | 225 | 94 |
JPP32 | 32 | 80 | 100 | 213 | 46 | 165 | 69 |
JPP36 | 36 | 90 | 100 | 178 | 41 | 178 | 78 |
JPP40 | 40 | 100 | 100 | 150 | 36 | 190 | 87 |
JPP43 | 43 | 110 | 80 | 152 | 43 | 135 | 60 |
JPP48 | 48 | 120 | 80 | 130 | 38 | 145 | 62 |
JPP56 | 56 | 140 | 60 | 120 | 44 | 85 | 44 |
JPP59 | 59 | 150 | 60 | 110 | 42 | 98 | 46 |
JPP64 | 64 | 160 | 60 | 100 | 37 | 105 | 50 |
JPP72 | 72 | 180 | 50 | 90 | 41 | 82 | 39 |
JPP80 | 80 | 200 | 50 | 75 | 36 | 90 | 43 |
JPP100 | 100 | 250 | 40 | 60 | 36 | 65 | 35 |
JPP120 | 120 | 305 | 40 | 43 | 25 | 70 | 29 |
JPP130 | 130 | 330 | 40 | 37 | 23 | 75 | 31 |
JPP140 | 140 | 355 | 30 | 38 | 33.7 | 60 | 33 |
JPP150 | 150 | 381 | 30 | 34 | 30.25 | 52 | 26 |
JPP165 | 165 | 420 | 30 | 28 | 20.7 | 51 | 29 |
JPP180 | 180 | 460 | 30 | 25 | 19.5 | 58 | 31 |
JPP200 | 200 | 510 | 30 | 16 | 10.2 | 58 | 35 |
Fabric number
The fabric number is composed of:
Mesh-count n 110-80W PW Thread ∅ dnom 110-80W PW Fabric colour 110-80W PW
(White = W; yellow = Y) Type of weave 110-80W PW (Plain Weave = PW)
