Nylon Mesh Woven Filters for Scientific and Laboratory Research
Precision Filtration Solutions for Cellular Separations, Tissue Culture, and Colony Transfer
SHARE precision nylon filter mesh is manufactured using mono-filament PA6 or PA66 yarn/thread (1:1 weaving method, plain weave), providing ideal straining, sieving, and filtering capabilities. The mono-filament construction features single smooth solid strands with precise, uniform diameters for consistent performance.
Key Advantages
- Excellent dimensional stability and precision mesh openings
- Smooth surface for easy particle separation
- Superior strength, elasticity, and abrasion resistance
- Resistant to alkalis, chemicals, solvents, fuels, and lubricants
- Higher moisture absorbency compared to polyester
- Available in various shapes and mesh openings (3μm to 2500μm)
- Compliant with food grade standards and RoHS/REACH certified
Applications
| Application |
Purpose/Technique |
Filter Characteristics |
| Cellular Separations |
Isolation and separation of cell types |
Pore size selection for specific cell size exclusion, durability |
| Tissue Culture |
Support for cell growth |
Porous surface for nutrient/gas exchange, cell adhesion support |
| Colony Transfer |
Bacterial or yeast colony transfer |
Facilitates transfer of colonies for further analysis |
| Plaque Lifts |
Transfer of viral plaques |
Used in virology for transferring viral plaques |
| Immunology |
Western blotting, ELISA, etc. |
Filtering or separation of components in immunological assays |
| HPLC Sample Preparation |
Preparing samples for HPLC |
Removes particulate matter for improved performance |
Specifications
Product Details
- Manufacturer: Taizhou Share Filters Co., Ltd.
- Brand: SHARE FILTERS
- Material: 100% nylon monofilament mesh
- Color: Natural white
- Weave Types: Plain woven, twill woven, dutch woven
- Mesh Opening: 3μm to 2500μm
- Open Area: 1% to 67%
- Thickness: 50μm to 1900μm
Product Forms
- Roll Width: 1cm to 390cm (standard widths available)
- Roll Length: 30-100 meters or customized
- Product Types: Roll, disc, ribbon, shapes, bag, pleated components
- Shapes: Round, square, rectangular, trapezoidal, circular
- Processing: Colored, coated, thermal treated, sectioned, shaped
- Certifications: ISO19001, SGS, ROHS, REACH
- Samples: 1 meter free sample available
Technical Data Sheet
| Fabric Number |
Mesh Count |
Thread Diameter |
Mesh Opening |
Open Area |
Mesh Thickness |
Weight |
| PA 3233/58.3 |
2.3 n/cm | 6 n/inch |
1000 μm |
3233 μm |
58.3% |
1900 μm |
412 g/m² |
| PA 2300/51.3 |
3.1 n/cm | 8 n/inch |
900 μm |
2300 μm |
51.3% |
1700 μm |
450 g/m² |
| PA 1950/61 |
4 n/cm | 10 n/inch |
550 μm |
1950 μm |
61% |
950 μm |
262 g/m² |
Complete technical data available upon request. Specifications subject to change without notice.
Production Process
Yarn
- Excellent diameter control for precise openings
- High flow rates and low pressure drops
- Filtration by surface particle capture
- Easy to clean with excellent surface particle release
- High degree of stiffness
Weaving
Plain weave construction crosses warp and weft yarns for durability and friction resistance. The uniform structure provides consistent performance with many thread crossing points.
Product Gallery
Contact SHARE for additional images and application examples of our fabricated mesh filters.
Company Profile
Established in 1983, Taizhou Share Filters Co., Ltd. specializes in woven monofilament filter mesh fabrics with micron ratings from 3μm to 4mm. Our 30+ years of experience enables us to engineer woven fabrics into finished products meeting precise specifications.
Monofilament Mesh Rolls
- Materials: PA, PET, PP, PE, PPS, PEEK
- Precise mesh opening, open area and thickness
- Full converting capabilities from yarn to finished products
Fabricated Components
- Discs, tubes, ribbons, bags
- Cutting, welding, slitting, sewing, pleating
- Cold, heat, laser, ultrasonic processing
- Clean, smooth edges
Packaging & Shipping
Mesh Rolls
- Rolled on paper core (30-70m/roll)
- PE bag packaging with product label
- 2-8 rolls per export carton
- PP woven bag for transport protection
Fabricated & Molded Filters
- Sealed PE bags (10-500pcs/bag)
- Double bagged with inner label
- Standard export carton
- PE stretch film wrapping
Shipping Options
| Method |
Port to Port |
Door to Door |
| Express (DHL, UPS, FEDEX, EMS) |
1-5 days |
1-5 days |
| Air Freight |
1-5 days |
4-10 days |
| Sea Freight (FCL) |
15-30 days |
20-35 days |
| Sea Freight (LCL) |
15-30 days |
22-37 days |
Frequently Asked Questions
Where is your factory located? How can I visit there?
We are located in Taizhou city, Zhejiang province, China. Our facility is approximately one hour by train from Hangzhou and two hours from Shanghai.
Can I get free samples and how long can you deliver them?
We provide free samples for evaluation, typically shipped within 2 days of request.
How long does a quotation take?
We respond to most quotation requests within 2 days. If additional information is required, we will notify you promptly.
What about your quality control?
Our quality control includes visual inspections, optical/pressure sensitive equipment, and automated 3D image-inspection at every production stage, plus final QC inspections.
