Mono-filament PA6/PA66 Precision Woven Nylon Mesh Woven Filters With 3um To 2500um Micron Ratings For Straining, Sieving, Filtering Applications

Minimum Order Quantity :	200 pcs	Price :	$1 for 500 pcs, $0.9 for 10,000 pcs, $0.7 for 50, 000 pcs
Packaging Details :	PE bag and carton	Delivery Time :	5 working days
Payment Terms :	L/C,T/T,Paypal	Supply Ability :	1, 0000 pcs / day

Place of Origin:	Zhejiang, China	Brand Name:	SHARE FILTERS
Certification:	Reach Svhc, SGS RoHS, California Proposition 65	Model Number:	SG-NS-11

Detail Information
Material:	Nylon(PA), Polyester(PET), Polypropylene(PP), Polyethylene(PE) Filter Mesh	Form:	Roll, Disc, Ribbon, Shapes
Micron Ratings:	3um To 2500um	Processing Technologies:	Ultrasonic, Laser, Heat Cut, Cold Cut
Edge Quality:	Precise Clean Edge	Feature:	Great Precision Smooth Surface Abrasion Resistance
Highlight:	Food Processing Nylon Mesh Woven Filters , Cosmetic Processing Nylon Mesh Woven Filters

Product Description

Nylon Mesh Woven Filters

Precision nylon filter meshes are made of mono-filament PA6 or PA66 yarn/thread (1:1 weaving method, plain weave), ideal for straining, sieving or filtering applications across multiple industries.

Key Advantages

Excellent dimensional stability and precision mesh openings
Smooth surface for easy particle separation
Superior strength, elasticity, and abrasion resistance
Good resistance to alkalis, chemicals, solvents, fuels and lubricants
Higher moisture absorbency compared to polyester
Available in various shapes and mesh openings (3μm to 2500μm)
Compliance with food grade standards
RoHS and REACH certified

Industry Applications

Photoresist/Semiconductor Manufacturing: Removing particulates from chemicals
Electronic Fluid Filtration: Protecting sensitive components
Business Machines & Appliances: Preventing dust entry
Automotive Equipment: Air intake and fuel filtration

Pulp & Paper Production: Removing impurities from solutions
Food Processing: Liquid and air filtration
Cosmetic Processing: Ensuring ingredient purity
Wine & Beer Clarification: Removing sediment and yeast

Technical Specifications

Material	100% nylon monofilament mesh
Weave Types	Plain woven, twill woven, dutch woven
Mesh Opening	3μm to 2500μm
Open Area	1% to 67%
Thickness	50μm to 1900μm
Roll Width	1cm to 390cm (standard widths available)
Product Forms	Roll, disc, ribbon, bag, pleated components in various shapes
Certifications	ISO19001, SGS, ROHS, REACH

Product Gallery

Contact SHARE for more images and application examples of our fabricated mesh filters.

Production Process

Yarn: Monofilament with excellent diameter control for precise openings

Weave: Plain weave construction for durability and uniform filtration

Full Production Procedure:

Yarn → Raw yarn inspection → Warping arranging → Drawing in heddle → Drawing in reed → Weaving → Initial survey → Washing → Heat setting treatment → Physical properties inspection → Products inspection → Fabricated mesh if needed → Plastic molded filters if needed

Company Profile

Established in 1983, Taizhou Share Filters Co., Ltd. specializes in woven monofilament filter mesh fabrics with micron ratings from 3μm to 4mm.

Monofilament Mesh Rolls

30 years of experience
PA, PET, PP, PE, PPS, PEEK materials
Precise mesh opening control

Fabricated Components

Discs, tubes, ribbons, bags
Various converting technologies
Clean, smooth edges

Our application specialists can help design the best filter solution for your specific requirements.

Packaging & Shipping

For mesh rolls:

Rolled on paper core, 30-70m/roll
2-8 rolls per export carton
PP woven bag protection

For fabricated & molded filters:

Sealed PE bags with product labels
Standard export cartons
PE stretch film protection

Shipping Method	Port to Port	Door to Door
Express (DHL, UPS, FEDEX, EMS)	1-5 days
Air Freight	1-5 days	4-10 days
Sea Freight (FCL)	15-30 days	20-35 days
Sea Freight (LCL)	15-30 days	22-37 days

Frequently Asked Questions

Where is your factory located? How can I visit there?

We are in Taizhou city, Zhejiang province China, approximately one hour from Hangzhou and two hours from Shanghai by train.

Can I get free samples and how long can you deliver them?

We provide free samples for evaluation, typically delivered within 2 days.

How long does a quotation take?

We respond within 2 days in most cases.

How quickly can I get my order finished?

Production typically takes 5 to 15 working days depending on quantity.

What about your quality control?

We conduct inspections at every production stage using visual, optical, and automated 3D image-inspection equipment.

The data are compiled to the best of our knowledge. Subject to change without notice. Current data are available on demand.
