Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen

Minimum Order Quantity : 1000pcs Price : USD0.04-USD1.00/pc
Packaging Details : Caron, Polybag Delivery Time : 3-9 days
Payment Terms : T/T, L/C, D/P, Western Union, PayPay Supply Ability : 20000pcs/day
Place of Origin: China Brand Name: Share Filters
Certification: Rohs Model Number: Nylon Mesh Tube for ABS Systems Screen

Detail Information

Product Name: Nylon Mesh Tube For ABS Systems Screen Keywords: ABS Systems Screen Mesh Tube
Material Option: Nylon Filter Mesh, Polyester Filter Mesh Micron Rating: 300μm-1500μm
Fabricated Method: Heat Or Sonic Welding, Cutting Size: Any Custom Size Or Shapes
Application: Brake Filter, Other Automotive Filter
High Light:

ABS Brake Systems Screen Welded Tube


Nylon Filter Mesh Welded Tube


Automotive Fabricated Filter Tube

Product Description


Nylon Filter Mesh Welded Tube for Automotive ABS Brake Systems Screen


Nylon filter mesh is the most popular and economical synthetic filtration mesh, Share weaves nylon filter mesh with Sulzer P7100 looms. More than 20 years of production experience enables us to weave nylon filter mesh with precise and uniform mesh holes. These versatile precision woven meshes meet stringent technical requirements in automotive, biomedical, chemical processing, and water treatment applications. Common applications include insert-molded filters for air and fuel filter cartridges, fuel injector nozzles, and liquid filter bags.


Converting Filter Mesh To Be Mesh Strips, Pieces, Tubes, Moulded Filter


Share Filters not only offers a wide range of specifications of nylon filter mesh in rolls, we also process the filter mesh into all kinds of filter components. Thanks to the advanced process equipments and many years of experience, Share Filters' filter mesh pieces and tubes can be tailored to any shape or dimension. Laser cutting allows for elaborate shapes to be cut that are specific to the customer’s design needs. The  mesh pieces can be created in double layers. Share Filters has the competence to manufacture tubes either by heat slitting or by ultrasonic welding. By slitting two layers of mesh simultaneously, the heat emitting from the slitting facility will weld both sides together creating a tube. These mesh pieces and tubes are suitable for mesh insert injection moulding and simple and cheap in production. For higher weld strength, we recommend ultrasonic welded tubes having one overlapping weld.



Share Filters' Filter Mesh Options for ABS Brake Systems Screen


Material Options: Monofilament woven nylon filter mesh, polyester filter mesh
Mesh Opening: From 200 micron to 1500 micron
Thread Diameter: From 100 micron to 500 micron
Mesh Count: From 12 mesh to 80 mesh
Weave Type: Plain weave
Fabricated Part: Sheets, pieces, strips, tubes, discs, shapes, ribbons
Dimension: Can be tailored to any shape or dimension
Colour: White, or customize



Product Details


Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 0 Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 1


Share Filters can supply mesh filter elements in every stages, from the mesh in rolls to final moulded filters.


nylon filter mesh ribbon
  • Slitted filter mesh ribbon
Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 3
  • Cutted pieces, precise size is convenient for installment
Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 4
  • Welded mesh filter tube, convenient for injection moulding
mesh insert injection moulded filter
  • Mesh insert injection moulded filter




Benefits from Precut Nylon Mesh Tubes:

  • Specific to the customer’s design needs
  • Wide range of micron rating and thread diameter options
  • Non-fraying and clean edges(depends on the technology)
  • Convenient for insert moulding
  • High productivity

The Property of Nylon Filter Mesh:

  • High tensile strength and cost-effective
  • Precise and even mesh opening
  • Elasticity and flexibility
  • Resistance to chemicals, fuel and oils
  • Easy cutting, dyeing, and cleaning



Nylon Filter Mesh Specifications for ABS Brake Systems Screen


Fabric Number Mesh Count Thread Diameter Mesh Opening Open Area Mesh Thickness Weight
  n/cm n/inch μm μm % μm g/m2
PA 1500/56 5 12 500 1500 58 850 271
PA 1267/58 6 16 400 1267 56 780 208
PA 1079/57 7 18 350 1079 57 675 186
PA 900/52 8 20 350 900 52 685 212
PA 860/60 9 24 250 860 58 455 145
PA 700/49 10 25 300 700 49 576 195
PA 583/49 12 30 250 583 49 470 162
PA 533/41 12 30 300 533 41 585 234
PA 414/34 14 35 300 414 34 595 273
PA 425/46 16 40 200 425 46 370 139
PA 375/36 16 40 250 375 36 485 217
PA 350/49 20 50 150 350 49 375 98
PA 300/36 20 50 200 300 36 385 173
PA 267/41 24 60 150 267 41 285 117
PA 237/44 28 70 120 237 44 215 87
PA 213/41 30 76 120 213 41 225 94
PA 213/46 32 80 100 213 46 165 69


This just a part of specifications which common used.


 Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 6

Mesh count (n/cm), (n/in)

The mesh count stands for the number of openings per inch.


Mesh opening (w), (μm)

The mesh opening w is the distance between two adjacent warp or weft thread.


Thread diameter (d),( μm)

The thread diameter is measured on the thread before weaving.


Open area (%)

The percentage of the open are is the sum of all mesh openings as percentage of the total fabric area



Share Filters Other Fabricated Filter Mesh Parts


filter mesh ribbon nylon filter mesh discs Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 9 polyester mesh tube nylon biopsy bag
Slitted mesh ribbon Mesh Disc Mesh Shape Mesh tube Welded bag



Properties of Polymers


Share Filters’ line of specialty filter meshes is ideal where high temperature, chemical resistance and material fatigue are common.


Material PA6 PA66 PET PP PEEK
Specific gravity (g/mm²) 1.14 1.14 1.38 0.91 1.3
Tensile strength(daN/mm²) 41-67 41-67 45-75 35-62 33-75
Relative strength at wet conditions(%) 89-90 85-90 100 100 100
Elongation at break (%) 20-35 20-35 15-30 20-50 20-40
Moisture absorption at 20°C / 65% r.h. (%) 3.5-4 3.5-4 0.4 0 0.1
Melting point (°C) 210-220 260-268 250-260 165-175 334
Softening point (°C) - - 220-240 140-155 300
Working temperature dry (°C) - - -75 to +150 -30 to +90 up to 250
Stability to light poor poor poor poor good
Atmospheric influence - - none none none
Abrasion resistance good good limited limited good
Acid resistance limited-poor limited-poor good good good
Alkaline resistance good good limited good good
Stability to solvents limited limited good good good
Hydrolysis resistance good good limited good good



Why Work With Share Filters ?

Share Filters specializes in helping our customers design and manufacture high quality mesh filter components to around the world. As a supplier combining the filter mesh manufacturing and filter mesh processing according to custom-made design, we are flexible enough to adapt to our customers’ production and delivery needs. Our advanced manufacturing processes and scientific machines allow us to create filtration products in any shape or structure – from simple components like mesh pieces to complex devices like custom combination plastic moulded filters. Filter mesh shapes, bags, Injection-moulded filters and similar products of various shapes, sizes and filter meshes are our primary business.


We're the suppliers who have experience with synthetic filter meshes and are able to use them with plastic moulding in good conditions. The molding technique requires special tools and above all a great deal of know-how. We make serial injection moulding tools, assembly preparations and procedures ourselves. Filters and parts are produced, assembled, quality controlled and packed.


filter mesh weaving

Precise Filter Mesh Weaving


The width of filter mesh rolls can be in 100cm, 127cm, 150cm, 165cm, 175cm, 183cm, 365cm or other custom width. Length of roll can be 30m, 50m, 70m, or other custom length.



Filter Mesh Slitted in Narrow Ribbons


Share Filters ribbons are used in a multitude of applications such as automotive filters, appliances filters, industrial filters, electronic devices, healthcare. Ribbons are often the basis for various further processing steps in numerous manufacturing processes for piece, tubes and bags. Advanced heat and ultrasonic slitting and cutting equipment enables the production of various kind of mesh ribbons with clean edges.

      Filter mesh slitted to be ribbons



Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 14

Filter Mesh Pre-Cut Pieces and Shapes

Share Filters cutting method include Laser cutting, Cold cutting, Heat cutting, Punching. Professional cutting using custom-made tools that will not damage the meshes. Laser cutting allows for elaborate shapes to be cut that are specific to the customer’s design needs.



Cutting and Welding Tubes


Share Filters has the competence to manufacture tubes either by heat slitting or by ultrasonic welding. The tubes are equipped with one or two functional seams according to the requirement, which provide the necessary seam strength. The ultrasonic welded tubes have one overlapping weld with more strength.

   Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 15


Ultrasonic Welded Mesh Bag Sewn Mesh Bag

Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 16

sewn filter mesh bag



Standard Filter Bags

Share Filters produces and provides high quality liquid filter bags to fit standard size filter housing, as well as custom designed bags where requested. The constituent materials have been chosen for their purity, with consistent high quality and repeatable performance.

Top design: plastic collar, metallic ring

      Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 18


Mesh insert plastic moulded filter

Mesh Insert Injection Moulded Plastic Filters


Our injection moulded filters products consist of a filter mesh held in a plastic frame. Injection moulding will drop hot plastic in a custom made mould with a synthetic or metallic mesh inside. Once cooled and solid, it can produce a very robust and reliable part or product that can be used for filters or screens.


Application of Share Filters Products


Our customer base comes from a wide variety of industries including – Automotive, Home appliances, Food and beverage, Milling, Medical, Life Science and laboratory, Electronical as well as more general engineering, giving us a wealth of experience in many areas.


injector filter BIOPSY BAG Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 22 coffee filter Nylon Filter Mesh Welded Tube For Automotive ABS Brake Systems Screen 24 MESH DISC FILTER
Fuel filter Biopsy bag Air purifier filter Coffee filter  Irrigation filter Mesh disc filter
Automotive Laboratory Appliance Food & Beverage Agriculture Power tool
