120 Mesh 130 Micron Pore Size Nylon Filter Mesh Sheets Shapes In Custom Size

Product Description

120 Mesh 130 Micron Pore Size Nylon Filter Mesh Sheets In Custom Size

Share Filters is striving to produce and supply our clients with standard and custom-made mesh filter elements. Thanks to advanced processing equipments and rich experience, Share Filters provides filter meshes cut to size, lot-to-lot consistency and high quality custom fabricated components, shapes are cut polygons or irregular cut flat pieces. We are happy to advise the best fabrication technology according to your drawing.

The shapes of filter mesh fabrics can be performed classically or conventionally through different cuts or processes. There are several possibilities types according to the requirements of your filtration process:

• Cutting into all possible shapes.
• Slitting meshes into ribbons.
• Welding mesh tube.
• Mesh insert moulding filters.

Benifits of Share Filters' Nylon Mesh Shapes:

• Cut to any size, shapes based on customers' specification, drawing, or samples.
• Various kinds of filter materials with specifications available, such as polyester filter mesh, nylon filter mesh, polypropylene filter mesh, metallic-fiber filter mesh as well as needle punched filter felts.
• Slitting, laser cutting and ultrasonic cutting secures the mesh edges from fraying.
• High precision opening, uniform thread diameter
• Available in singe layer or double layers, disc, polygon, irregular and other special shapes
• Compliance with food grade

Share Filters' Nylon Filter Mesh Can Be Tailored To Virtually any Shape or Dimension.

• Laser cutting allows for elaborate shapes to be cut that are specific to the customer’s design needs. Laser cut parts can be also produced in multiple layers. The high-precision laser cut parts are characterized by closed edge quality.
• Ultrasonic stamping is available for fabrics having mesh openings < 400 µm. It ensures tight tolerances and provides high-quality sealed edges which do not fray.
• Cold cutting combines a roller cutter with the traditional scissors for cutting fabrics that can’t be cut with other methods.

Laser cutting	Ultrasonic cutting	Cold cutting



Share Filtes Filter Mesh Shapes Materials Options

	Filter media	Nylon mesh, polyester mesh, PP mesh, stainless steel mesh
	Micron rating	20μm - 900μm
	Mesh fabrication	Laser cutting, ultrasonic cutting, punching
	Specification	Custom

Nylon Mesh

Compared with polyester, nylon mesh has higher water absorption rate, unrivaled strength resistant to cyclic deformation, is robust against friction and bending, and is highly elastic as it's characteristics. It also features resistance to chemicals and oils, as well as being resistance to alkalis.

Polyester Mesh

Polyester is one of the strongest fibers and remains resistant even if it gets wet and exposed to friction. Its low moisture absorbency prevents it from expanding, contracting, becoming wrinkled, and it also features resistance to chemicals, as well as being dimension stability.

Polypropylene Filter Mesh
Polypropylene mesh is chemical resistant and non-absorbent, with good weather, acid and alkaline resistance.

Stainless Steel Filter Mesh
Stainless steel filter mesh is with the following benefits: corrosion resistance, strength and durability, high temperature resistance, versatility, easy maintenance and cleanliness, environmental friendliness


Nylon Filter Mesh Specifications


What Share Filters Do


Share Filters specializes in helping our customers design and manufacture high quality mesh filter components to around the world. As a supplier combining the woven mesh manufacturing and mesh processing according to custom-made design, we are flexible enough to adapt to our customers’ production and delivery needs. Our advanced manufacturing processes and scientific plastic molding allow us to create filtration products in any shape or configuration – from simple, traditional components like mesh shapes to highly complex devices like custom plastic filters.

Factory Capabilities
Mesh weaving, Mesh Slitting, Cutting Shape, Welding, Sewing, Injection molding.


Share Filters Workshops


Share Filters Products Applications

Fuel filter	Tranfusion filter	Air purifier filter	Proofer cup	Drip irrigation filter
Automotive	Healthcare	Appliance	Food & Beverage	Agriculture
