Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment
Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment
Contact Now

Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment

Minimum Order Quantity : 100meters Price : USD0.2-USD3.5
Packaging Details : Caron Delivery Time : 5-10 days
Payment Terms : T/T, L/C, Western Union, MoneyGram Supply Ability : 1000meters/day
Place of Origin: CHINA Brand Name: SHARE
Certification: SGS Model Number: 8/20-300W~165/420-34W

Detail Information
Material: Monofilament Polyester Yarns Mesh Count: 20tpi-420tpi
Mesh Openning: 950um-23um Thread Diam.: 300um-34um
Weave Type: Plain Weave Colour: White, Black, Yellow, Customized
High Light:

Plain Weave Polyester Mesh Fabric

,

Outdoor Polyester Mesh Screen

,

Polyester Monofilament Mesh 23um

Product Description

Excellent Dimensional Stability Polyester Filter Mesh Rated From 950um To 23um Suitable Solution For Outdoor Environment



As an important factor of filter press, polyester filter cloth has been widely accepted by an increasing number of manufacturers and users of filter press for its strongest acid-resistance and excellent resistance against elevated temperature up to 130 °.



Properties and Advantages of Polyester Mesh Fabric

  • Ease of use and accessibility.
  • Excellent dimensional stability
  • High strength and durability
  • Hydrophobic surface
  • Extended screen service life
  • Resistance to acids/alkalis, corrosion, ultraviolet light, and wear

These advantageous characteristics make polyester mesh suitable for a wide range of applications. The hydrophobic nature of polyester fibers allows them to repel moisture. As a result, polyester mesh screens will dry faster when exposed to wet conditions. Additionally, polyester is more resistant to heat and UV rays than nylon, making filter mesh more suitable solution for outdoor environments.



Polyester knit mesh is a material solution that finds use across a wide range of industrial, commercial, and recreational sectors. Its strength,     stability, and durability make it well-suited for many applications.



Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment 0Plain Weave Monofilament Polyester Filter Mesh 23um For Outdoor Environment 1



Product Datesheet:

Mesh count

(per cm/inch)

Type of weave

(tw or pw)

 Thread diameter (microns) Mesh opening (microns) Overall fabric thickness (microns) % Open area Theoretical
ink deposit (cm3/m2)		 Mesh Weight (gsm)

8/20-300W PW 300 950 560 57.8 323.5 169
10/25-260W PW 260 739 498 54.6 272.0 158
12/30-140W PW 140 688 256 68.2 174.7 55
15/40-200W PW 200 465 353 48.6 171.5 141
18/45-180w PW 180 375 330 45.5 145.5 128
21/54-140W PW 140 333 250 49.0 122.5 96
24/60-120W PW 120 294 210 49.7 104.3 81
27/70-120W PW 120 249 210 45.3 95.0 91
30/76-120W PW 120 211 212 40.2 82.4 101
32/83-70W PW 70 240 117 58.7 68.7 37
32/83-100W PW 100 209 166 44.5 72.1 75
36/92-90W PW 90 183 147 43.3 64.9 68
36/92-100W PW 100 174 162 39.1 62.6 84
40/103-80W PW 80 166 133 44.1 58.6 60
43/110-80W PW 80 149 130 40.8 53.0 64
45/115-80W PW 80 138 130 38.7 50.3 67
48/123-80W PW 80 122 130 34.5 44.8 72
48/123-55W PW 55 151 90 52.8 47.5 34
51/131-70W PW 70 121 114 38.1 43.5 58
54/137-64W PW 64 115 103 38.7 39.8 51
61/156-64W PW 64 90 101 30.1 30.4 58
68/175-55W PW 55 85 87 33.5 28.4 48
68/175-64W PW 64 78 98 28.2 27.6 65
71/180-55W PW 55 79 90 31.5 28.4 51
77/195-48W PW 48 77 80 35.0 28.0 42
77/195-55W PW 55 67 87 26.5 23.3 55
82/206-48W PW 48 68 79 30.8 24.3 44
90/230-40W PW 40 68 65 37.6 24.4 33
90/230-48W PW 48 55 78 24.6 19.2 49
100/255-40W PW 40 57 64 32.5 21.1 37
110/280-34W PW 34 54 55 35.2 19.3 31
110/280-40W PW 40 47 65 26.6 17.3 40
120/305-34W PW 34 45 55 29.6 16.3 34
120/305-40W PW 40 37 64 20.1 13.0 44
130/330-34W PW 34 40 55 26.9 14.3 37
140/355-34W PW 34 31 55 19.4 10.6 39
150/380-34W PW 34 23 55 12.1 6.6 42
165/420-34W PW 34 23 62 13.9 8.6 46
